Basic Info.
Product Description
General specifications
step angle accuracy : ±5% (full step, no load)
resistance accuracy : ±10%
inductance accuracy : ±20%
temperature rise : 80°c max.(rated current, 2 phase on)
ambient temperature : -20°c ~ +50°c
insulation resistance : 100 m o min. ,500v dc
dielectric strength : 500v ac for one minute
shaft radial play : 0.02 max. (450 g-load)
shaft axial play : 0.08 max. (4200 n (20 mm from the flange) 50 g-load)
max. radial force : 60 n
visit to http://www.tinycontrols.com/stepper-motor.html for more details.
specification
series model : t110h150-6504
motor length : 150 mm
phase current : 6.5 a
phase resistance : 0.67 ohm
phase inductance : 13.12 mh
holding torque : 19 nm
detent torque : -
rotor inertia : -
leads wires : 4
