Product Description
Application of Tensile Tester: Tensile Tester is applicable in the test of mechanical properties of plastic film, laminated material, flexible packaging material, plastic flexible tube, adhesive tape, pressure sensitive tape, adhesive bandage(plaster), release paper, protective film, flip off cap, foil, diaphragm, back sheet, non-woven, rubber and paper fiber, etc. It can perform the test items of tensile, peeling, deformation, tearing, heat seal, adhesive, puncture force, open force, low-speed unwinding force and unsnapping force, etc.
Features of Tensile Tester:
1. Minicomputer control, LCD displays data, results and curves,
2. Menu interface, PVC operation board,
3. Data memory function when power failure, overload protection, position limit protection and auto return,
4. Standard measurement units,
5. Four measurement ranges, accuracy: ±1%,
6. 7 independent testing programs, including ensile, peeling, tearing and heat seal, etc,
7. Multi-functions of parameter set, printing, inquiry, clear and calibration, etc,
8. Group sample statistical analysis and calculation, curve,
9. RS232 interface, printer interface (mini-printer),
10. Top quality sensor, high accuracy and stability,
11. Network transmission interface for LAN data management and internet data transmission.
Technical parameter of Tensile Tester:
1. Specification: 30N, 50N, 100N, 300N, 500N, 1000N,etc(optional),
2. Stroke: 450mm [optional],
3. Load measurement range: 2%-100% of max load,
4. Load measurement accuracy: ±1% ,
5. Force measurement: 1, 2, 5, 10 four testing steps,
6. Test Speed: stepless speed regulation available, or 1, 2, 5, 10, 20, 50, 100, 200 (500) min/mini, optional step,
7. Speed accuracy: ±2%,
8. Dimensions: 1350 (L) x 450 (B) x260 (H) mm,
9. Power: AC 110-220V 50-60HZ,
10. Net weight: 65kg.
Note:
1. Standard configuration: Mainframe, standard jig, mini-printer,
2. Optional configuration: Computer, software, peeling jig, puncture jig, compressing jig, sampling cutter, standard roller, non-standard clamps
Recommend reasons of Tensile Tester:
1. International advanced technology,
2. Human-machine friendly design, easy operation, keeping handlers safe,
3. Reasonable price.
Keywords of Tensile Tester:
1. Standard: ISO 37, ASTM E4, ASTM D828, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, JIS P8113, QB/T 2358, QB/T 1130
2. Others: Tensile strength tester, tensile testing, tensile test, tensile test machine, tensile test equipment, tensile testing machine, test tensile.
