Product Description
Detailed Product Description
Model: CJ100
1. Punching force(kN): 1000
2. Printing force(kN): 800
3. Thickness range of workpiece(mm): 6-25
4. Max. Workpiece dimension(mm): 1500*800
5. Number of station: 3
6. Max. Pinching diameter(mm): 31.5
7. Min. Margin distance from punching center(mm. Punching diameter 25.5): 25
8. Number of letter(mm): 14or 18
9. Size of letter(mm): 14*10
10. Working accuracy: GB2694-81
11. Overall dimension(mm. FR*LR*-H)3020*2522*1875
GB/T19001-2000 ---- ISO9001: 2000
Technical Charecteristics:
1. Integrated machine with machanical, electrical and hydraulic systems;
2. PLC control and servo-motor feed-in;
3. Self-diagnostic function;
4. Easy programming and connectable with data generated directly from copying the specimen.
Advantages:
1. Modular assembling for main functional parts, easy maintenance;
2. Punching, printing and drilling operations on one plate;
3. Efficient drilling operation by fast approach, slow working and fast return progra
