Steel wire mesh welding machine

Product Description

Application: Construction mesh, enclosure mesh, seedbed mesh, 3D panel covered mesh Main Features: 1. the line wire feeding is from coil wires automatically. 2. Both the line wire spacing and cross wire spacing can be adjusted manually within certain range. 3. The cross wire feeding is in pre-cut wire. The originative cross wire feeding disc driven by step motor can drop cross wire one by one automatically into welding, which structure is compact and more reasonable. 4. The finished product can be in mesh sheet or mesh roll. If the output form is in mesh roll, the machine will be equipped with the mesh coiling machine. If the output form in mesh sheet, th emachine can be equipped with the automatic mesh cutter or manual mesh cutter. The automatic mesh cutter can cut the mesh to the desired length automatically without stop welding. Model LM-2A/250 Line wire diameter f3.0-5mm Cross wire diameter f3.0-5mm Line wire spacing 50-150mm Cross wire pitch 50-150mm Mesh width 900-2500mm Max. line wire no. 48 Mesh length As long as you require Line wire feeding form Coil wires Cross wrie feeding form Pre-cut wires Max. welding speed 50 rows of cross wires/min. Mesh output form In mesh sheets or mesh rolls Wire material Mild steel wire, galvanized wire Power supply 380v or customized
