Basic Info.
Product Description
Features:
â— compatible with esc/pos, star two kinds of instruction patterns;
â— support kitchen printing and network print;
â— support printer monitor function;
â— web embedded webpage, directly through the ie to configure the printer;
â— interface for the usb+ serial port, network port (100mb);
â— printer support authentication, computer software;
â— support drive high-speed download and print, the highest increase speed;
â— can automatically recover print;
â— network disconnection;
â— usb communication using virtual serial port mode, also supports the opos application;
â— a standard gb18030 simplified chinese characters library;
â— 100m card, connect / print more quickly, to avoid losing situation;
receipt printer specification:
printing print method direct thermal line
print width 64/76mm
dot density 512/576dot/line
print speed 250mm/s
interface serial+usb, ethernet
paper diameter 83mm
line space 3.75mm(can be adjustive)
character size ank font font a: 12×24dots font b: 9×17dots
simplified/traditional chinese character: 24×24dots
barcode code page pc437/katakana/pc850/pc860/pc863/pc865/west europe/
greek/hebrew/east europe/iran/wpc1252/pc866/pc852/
pc858/iranii/latvian/arabic/pt151,1251/pc737/wpc/
1257/thai vietnam/pc864/pc1001/(latvian)/(pc1001)/
(pt151,1251)/(wpc1257)/(pc864)/(vietnam)/(thai)
barcode mode upc-a/upc-e/jan13(ean13)/jan8(ean8)code39/itf/
codabar/code93/code128
fonts gb18030
buffer data 128k bytes
nv flash 256k bytes
power cashdrawer out dc 12v/1a
power supply ac 110v/220v,50 ~ 60hz,dc 24v/2a
physical properties
weight 1.18kg
dimension 170×135×115mm
environment work environment temperature:0 ~ 45℃, humidity:10 ~ 80%
storage environment temperature:-10 ~ 60℃ ,humidity:10 ~ 90%
auto cutter reliablity 150km
