Basic Info.

Product Description

Features: ● compatible with esc/pos, star two kinds of instruction patterns; ● support kitchen printing and network print; ● support printer monitor function; ● web embedded webpage, directly through the ie to configure the printer; ● interface for the usb+ serial port, network port (100mb); ● printer support authentication, computer software; ● support drive high-speed download and print, the highest increase speed; ● can automatically recover print; ● network disconnection; ● usb communication using virtual serial port mode, also supports the opos application; ● a standard gb18030 simplified chinese characters library; ● 100m card, connect / print more quickly, to avoid losing situation; receipt printer specification: printing print method direct thermal line print width 64/76mm dot density 512/576dot/line print speed 250mm/s interface serial+usb, ethernet paper diameter 83mm line space 3.75mm(can be adjustive) character size ank font font a: 12×24dots font b: 9×17dots simplified/traditional chinese character: 24×24dots barcode code page pc437/katakana/pc850/pc860/pc863/pc865/west europe/ greek/hebrew/east europe/iran/wpc1252/pc866/pc852/ pc858/iranii/latvian/arabic/pt151,1251/pc737/wpc/ 1257/thai vietnam/pc864/pc1001/(latvian)/(pc1001)/ (pt151,1251)/(wpc1257)/(pc864)/(vietnam)/(thai) barcode mode upc-a/upc-e/jan13(ean13)/jan8(ean8)code39/itf/ codabar/code93/code128 fonts gb18030 buffer data 128k bytes nv flash 256k bytes power cashdrawer out dc 12v/1a power supply ac 110v/220v，50 ~ 60hz，dc 24v/2a physical properties weight 1.18kg dimension 170×135×115mm environment work environment temperature:0 ~ 45℃， humidity:10 ~ 80% storage environment temperature:-10 ~ 60℃ ，humidity:10 ~ 90% auto cutter reliablity 150km
