| Model NO.: | Level gauge glass (boiler sight glass, liquid indicator glass)37466 |
|---|---|
| Min. Order (MOQ): | 0 |
| Customization: | Available Customized Request |
|---|
Level gauge glass Its made from Borosilicate, it is used in lever gauge in boiler for water position. It's also named water Gauge Glass, level gauge glass, boiler sight glass, liquid indicator glass, borosilicate sight glass, spars for level gauge. The category is as follows: 1) Reflex glass 2) Plain transparent glass 3) Round sight glass 1) Reflex Sight glass/gauge glass - three tendons (four grooves) 340 x 34(30) x 17mm, 320 x 34(30) x 17mm, 280 x 34(30) x 17mm 250 x 34(30) x 17mm, 218 x 34(30) x 17mm, 190 x 34(30) x 17mm 165 x 34(30) x 17mm, 140 x 34(30) x 17mm, 115 x 34(30) x 17mm 400 x 34 x 17mm, 370 x 34 x 17mm, 300 x 34 x 17mm 400 x 34 x 17mm, 370 x 34 x 17mm, 300 x 34 x 17mm The other size is optional or according to the requirements of customers. Working temperature: 260 C, Working pressure: 4.0MPa 2) Plain transparent sight glass/gauge glass 340 x 34 x 17mm, 320 x 34 x 17mm, 280 x 34 x 17mm 250 x 34 x 17mm, 218 x 34 x 17mm, 216 x 34 x 17mm 190 x 34 x 17mm, 165 x 34 x 17mm, 215 x 34 x 22mm 218 x 38 x 23mm, 190 x 38 x 23mm, 165 x 38 x 23mm The other size is optional or according to the requirements of customers. Working temperature: 260 C, Working pressure: 6.3 MPa 3) Round sight glass Thickness: 10mm-25mm Diameter: 50mm - 250mm Pressure: 6 - 25 bar Temperature: 250 Packing: Each piece in a box, then in cartons.
