| Model NO.: | Automatic knife grinder dmsq-1600k8892 |
|---|---|
| Packaging Qty: | Wooden packing |
| Manufacure Name: | Tianming |
| Customization: | Available Customized Request |
|---|
Tianming printing machine co.,ltd.of wenzhou
The main function characters of automatic knife grinding machine dmsq-1600k: drive mechanism 01. the main transmission is rack and pinion transmission 02. transducer timing devices: travel speed and the wheelhead speed adjustable machine structure 01. cantilever-type body: lathe bed casts with mezzo forte cast iron 02. rolling positioning linear guide: rail can be replaced, the life of machine is more longer, the maintenance costs of machine is more lower, the travel transmission of machine is more stable loading knife structure 01. electric magnetic chuck: uniform suction, milling knife is more straight-line, effectively improved the work efficiency main function deployment 01. grinding wheel automatic feed: automatic feed to grind knife 02. with a dust cover device 03. with memory, storage functions 04. plc programming control systems optional device 01. imports of electrical components: schneider electric (optional, costs excluded) 02. scraper clamp: dedicated for toilet paper device
