| Model NO.: | Plottercutter-cs47912 |
|---|---|
| Min. Order (MOQ): | 1 |
| Manufacure Name: | Shenzhen e-magic technology co.,ltd |
| Customization: | Available Customized Request |
|---|
Type CS630 Media Way M bracket or Stand Floor Stand Driver High speed stepping motor, micro-step driver Mainboard 32-bit ARM7 CPU , 4MB , High-speed CACHE memory Maximum paper feed width 730mm Maximum Cutting width 635mm Maximum Cutting Speed 1000mm / s Maximum Cutting length 20000mm <=20 Maximum Cutting thickness 1.0mm Cutting force 0-1000g(digital adjustment) Mechanical precision 0.05mm Repeatable precision < _0. 1mm Type of tool Carbide blade Type of Plot pen All types diameter 11. 4mm plotter pen Plotter Instruction Compatible DM/PL,HP/GL Interface USB2.0.Serial Port.SD Card.laserpoint Power Supply AC220V / 110V, 50Hz Operating environment: Temperature: 5_ 35, Relative Humidity: 30% ~70% External dimension 1030*375*450mm Shipping weight 29.5kg(0.178CBM) USB2.0.Serial Port.SD Card.laserpoint in one machine 128*64 blue background LCD High resolution,no noise,no los step,high speed 32 Bits ARM-MCU Control system,advanced technique,more smooth circle cutting,high speed
