Product Description
AZC206T mini-prospector is integrated, solid and intelligentized prospecting. Its pole adopts American's innovative and high technology, high resolution, high accuracy and high stability. It is adjusting to disturbing magentic field surrounding? Display cubes use powerful palm computer. The computer is touch screen, equipped with writing pad which can write directly on and label for measuring(It will introduce details in the operation principle).
AZC206T smart magnetic prospecting meter can be used for prospecting ore deposit of iron and nonferrous metal. It is also applied for ferromagnetic underground installation, such as water- supply pipe, iron pipe, reinforced concrete pipe, city underground infrastructure pipe etc. It can use for prospecting oil, coal and ferrous mix ore deposit.
Traits
1 Portable, easy operation, high intelligence
2 All-solid, hard to damage, simple maintenance.
3 High resolution, high definition, wide range, stable performance.
4 High anti-jamming capability.
5 Built-in temperature compensation adjustment.
6 Communicate with computer, store measuring data in computer and analyze.
7 Auto-graph, visual display lode profile map.
8 Large storage volume, it can store data of 80000 points.
Technical data
Direct detection: prospecting magnetite, oxy magnetite, vanadium titano-magnetite, gold and copper magnetite.
Indirect detection: metal bedrock of nickel, chrome, cobalt etc.
Ferromagnetic metal detection;
Detect axial direction: Vertical and horizontal component of geomagnetic field.
Measuring range: -100000nT~+100000nT
Resolution ratio: 1nT
Accuracy: <±0.5%(full range)
Measuring mode: full range direct measuring, do not need coarse adjustment, fine tuning and gear shift.
Data storage: 80000 points
Data acquisition frequency : 80 count per second.
Overall power consumption: 55mA~75mA
Power supply: all adopting recharge lithium batteries, 1100mA
Working environment: -10? ~ +50?,built-in temperature compensation.
Display mode: differentially mode, large screen LCD display,with backlight,adjusted brightness.
Probe size: ?88mm*60mm
Coarse measuring pole size: ?18mm*1000mm
Power supply data line: 1.5m
Probe weight: 0.6 Kg
Display weight: 0.3Kg
