Product Description
Model
AD-12CP4
AD-12CDNP4
Image Device
1/3 Sony CCD
Horizontal Resolution
420TV Lines
Minimum Illumination
0.5Lux
0.5Lux(D)/0.05(Lux)
Built-In Lens
3.7mm Super Cone Pinhole Lens(button lens,screw lens optional)
Dimension
12x12mm(15X15mm/16x16mm Optional)
Number of Pixels
PAL:(H)500x(V)582 / NTSC:(H)510x(V)492
Scanning System
PAL / NTSC
Sync System
Internal Synchronization
Video Output
1Vp-p 75O Negative
White Balance
Auto
A.G.C.
Auto
B.L.C.
Auto
S/N Ratio
More than 48dB
Gamma Characteristic
0.45
Electronic Shutter
PAL:1/50~1/100,000s ; NTSC:1/60~1/100,000s
Power Consumption
DC 12V
Operation Temperature
-10°C~+50°C
Storage Temperature
-20°C~+60°C
Accessories Furnished:
*DIY cable with BNC/RCA for Video,DC-Jack for Power;
*Microphone
*Manual.
Application: indoor
Connection: refer to FAQ
