Our concrete welded mesh is purposed for reinforcing flat concrete, mainly used for concrete floor slabs and walls as well as industrial buildings. the reinforcing steel bars are welded firmly which are not easy to crack. it's also called reinforcing mesh. technique data wire diameter of rebar: 3-12 mm. size of concrete welded mesh: 6 m × 2.4 m, 4.8 m × 2.4 m, 3.6 m × 2 m, 2 m × 4 m. common square mesh: 100 × 100 mm, 150 × 150 mm, 200 × 200 mm. material: cold rolled ribbed steel bar (deformed bar), hot rolled round bar, hot dipped galvanized or epoxy coating after production. standard: the production of mesh reinforcement complied to bs 4483/sans 1024. there are two sheet of concrete welded wire mesh. the top one is made by thinner wires, below with thick ones. different sizes of concrete weld wire mesh are available. they are made by various wire diameters.on the left there is a big concrete welded mesh. on the right, it's details of mesh: top - welding point, bottom - diameter of the wire. concrete welded mesh is made with accurate and uniform wires. these rebars are welded firmly.reinforcement steel bars are being welded into a mesh with machine. concrete weld mesh is made firmly with machine. they are mainly used in bridge, road, housing foundations.reinforcement steel bars of different sizes are tied together firmly. a large quantities of concrete welded wire mesh combined firmly make a strong foundation of construction. specification of square concrete welded mesh model line wire cross wire weight (kg/m2) dia. (mm) spacing (mm) area (mm2/m) dia. (mm) spacing (mm) area (mm2/m) s200-12 12 200 566 12 200 566 8.88 s200-11 11 475 11 475 7.46 s200-10 10 393 10 393 6.16 s200-9 9 318 9 318 4.99 s200-8 8 252 8 252 3.95 s200-7 7 193 7 193 3.02 s200-6 6 142 6 142 2.22 s200-5 5 98 5 98 1.54 s100-12 12 100 1131 12 100 1131 17.75 s100-11 11 950 11 950 14.92 s100-10 10 785 10 785 12.33 s100-9 9 635 9 635 9.98 s100-8 8 503 8 503 7.9 s100-7 7 385 7 385 6.04 s100-6 6 283 6 283 4.44 s100-5 5 196 5 196 3.08 s150-9 9 150 423 9 150 423 6.66 s150-8 8 335 8 335 5.26 s150-7 7 275 7 257 4.03 s150-6 6 189 6 189 2.96 s150-5 5 131 5 131 2.05 weight of concrete reinforcing mesh type line wire mesh /dia. (mm) cross wire mesh /dia. (mm) sheet length (mm) sheet width (mm) sheet weight (kg) number per bundle square meter per ton (m2) realsurface (m2) c200-5 200/5.0 200/5.0 4800 2400 17.74 60 649.38 11.52 c200-6 200/6.0 200/6.0 4800 2400 2557 46 45053 11.52 c200-7 200/7.0 200/7.0 4800 2400 51.85 26 222.18 11.52 c200-8 200/8.0 200/8.0 4800 2400 45.5 28 253.19 11.52 c100-6 100/6.0 400/6.0 4800 2400 31.96 32 360.45 12.15 c100-7 100/7.0 400/6.0 4800 2400 41.19 30 279.68 12.15 c100-8 100/8.0 400/6.0 4800 2400 51.85 26 222.18 12.15 specification of rectangular concrete welded mesh items longitudinal bar (4.8 m) cross bar (2.4 m) total area (kg/m2) weight (kg/sheet) size (mm) pitch (mm) area (mm2/m) size (mm) pitch (mm) area (mm2/m) r-4812 12 100 1131 8 200 252 10.9 125.57 r-4810 10 100 785 8 200 252 8.14 93.77 r-4808 8 100 503 8 200 252 5.93 68.31 r-4807 7 100 385 7 200 193 4.53 52.19 r-4806 6 100 283 7 200 193 3.73 42.97 r-4805 5 100 196 7 200 193 3.05 35.14 r-4810 10 100 785 6 400 70.8 6.72 77.41 r-4809 9 100 636 6 400 70.8 5.55 63.94 r-4908 8 100 503 6 400 49 4.51 51.96 r-4907 7 100 385 6 400 49 3.58 41.24 r-4906 6 100 283 6 400 49 2.78 32.03 note: other mesh sizes are also available. concrete welded mesh can be designed either in flat sheets, rolls or bent to suit for your requirements. there is a roll of concrete welded wire mesh. concrete weld mesh made of thinner wires could be rolled so that it's easy to transport.there are many pieces of concrete welded mesh on wooden pallet. thick concrete weld meshes are packed on one pallet.at construction site a piece of weld mesh is hang up with a machine. workers are preparing to catch it. reinforcing mesh is installed with a machine. workers are building a strong foundation of the bridge. advantage firm structure, precise opening, corrosion-resisting and oxidation-resisting. light and easy operation: it's light to be easier to move and lay on the concrete with machine. better crack resistance: our thinner wires can effectively reduce the crack width between concrete slabs. distributing the stress in 2-way more homogenously, it controls crack propagation as well as the crack width. application due to good durability, high tensile strength and toughness, concrete welded mesh is applied in many areas, such as: residential and industrial construction sectors: concrete floor slabs on fill, floor slabs reinforcement, suspended floor slabs, concrete wall, floor warming, brick wall reinforcement, power plants engineering. railways and port infrastructures: tunnel, drains, box culverts, concrete roads, highway, dam, river bank protection walls, airport runways. if you are interested can contact us via info@deformed-bar.com
