Product Description
General specifications
resistance accuracy : ±10%
inductance accuracy : ±20%
temperature rise : 80°c max.(rated current, 2 phase on)
ambient temperature : -20°c ~ +50°c
insulation resistance : 100 m o min. ,500vdc
dielectric strength : 500v ac for one minute
shaft radial play : 0.02 max. (450 g-load)
shaft axial play : 0.08 max. (4200 n ( 20mm from the flange )50 g-load)
max. radial force : 60 n
visit to http://www.tinycontrols.com/stepper-motor.html for more details.
specifications
series model : t57h76-2804
motor length : 76 mm
ph. current : 2.8 a
ph. res. (ohm) : 1.13
ph. inductance : 3.6 mh
holding torque : 18.9 kg-cm
detent torque : 480 g-cm
rotor inertia : 680 g-cm2
lead wires : 4
