Basic Info.
Product Description
- - - -
- - - -
production info. : |
- - - -
·automated calibration automated gain
·automated make video of test process and play
·dac avg & b scan, aws function, 6db dac
·high-speed capture and very low noise
·solid metal housing (ip65)
·high contrast viewing of the waveform from bright
·powerful pc software and reports can be export to excel features : · automated calibration of transducer zero offset and/or velocity ;
· automated gain?peak hold and peak memory;
· automated display precise flaw location(depth d?level p?distance s?amplitude?sz db??);
· automated switch three staff gauge ((depth d?level p?distance s);
· 100 independence setup, any criterion can be input freely, we can work in the scene without test block;
· big memory of 300 a graph and 30000 thickness value.
· b scan;
· rs232 port/ usb,communication with pc is easy;
· the embeded software can be online updated;
· li battery, continue working time up to 10 hours;
· other assistant function;
· display freeze;
· automated echo degree;
· angles and k-value;
· lock and unlock function of system parameters;
· dormancy and screen savers;
· electronic clock calendar ;
· two gates setting and alarm indication;
· high-speed capture and very low noise;
· dac?avg?b scan ; solid metal housing (ip65);
· automated make video of test process and play;
· provides high contrast viewing of the waveform from bright, direct sunlight to complete darkness and easy to read from all angles;
- - - -
main technical index: |
- - - -
- - - -
title | parameter | title | parameter |
measuring range(mm) | 2.5 ~ 10000 | measurement mode | single?dual?thru |
vertical linearity error | =3% | reject | 0~80% |
horizontal linearity error | =0.1% | pulse displacement(µs) | -20 ~ +3400 |
sensitivity leavings | 60db | zero(µs) | 0.0 ~ 99.99 |
pulse displacement | 32db | port type | bnc |
resolving power | =40 | operating temperature (?) | -20~50 |
frequency range(mhz) | 0.5 ~ 20 | h×w×d(mm) | 240×180×50 |
gain(db) | 0 ~ 110 | weight(kg) | 1.8 |
material velocity(m/s) | 1000 ~ 9999 | | |
- - - -
| |
standard delivery: main unit 2.5mhz-?20 straight probe 4mhz-8x9mm, 60degree angle probe 4a/9vpower adapter probe connection cable (bnc to lemo 00) probe connection cable (bnc to lemo 01) instruction manual carrying case additional acces
