Basic Info.
Product Description
3. technical specifications
display: 4 digits backlit lcd
measuring geometry: 60 degrees
range: 0.1 to 2 00 gloss units
accuracy: ± 1.0 gloss unit ( against reference standard )
resolution: 0.1 gloss unit
repeatability: ± 0.5 gu (0 ... 99.9)
measuring area: 7 x1 4 mm ellipse
data memorized: 254 groups
data output: rs232c serial interface
power supply: 4 x1 . 5 v aaa battery
dimensions: main unit: 156x67x28mm
separate sensor: 58x28x108mm
weight: about 300g ( including fitted batteries )
working condition: temperature range 0 - 40°c
humidity up to 85%
4. accessories
carrying case 1 pc
operation manual 1 pc.
external probe 1 pc.
holder with calibration standard 1 pc.
optic cleaning cloth 1 pc.
5. optional accessories
cable & software for rs232c.
usb adaptor.
bluetooth interface.
Company Profile
|
Business Type: |
Coating thickness gauge, ultrasonic thickness gauge, shore hardness tester, leeb hardness tester, surface roughness tester, surface profile tester, vibration meter, gloss meter |
|
Comapany: |
Guangzhou amittari instruments co., ltd. |
|
Address: |
42, huannan east street, huanhua rd. |
|
City: |
Guangzhou |
|
Zip/Postal: |
510375 |
|
Country: |
China |
.
